Product Overview
KASI supplies manually operated foot pumps for rent and sale across Canada and Alberta. These industrial foot pumps are built for demanding environments, offering a convenient hands-free pumping action with a wide foot pedal for easy, controlled operation. Designed with two-stage performance and durable steel construction, they deliver reliable hydraulic power up to 10,000 psi.
The manually operated foot pump provides safe, efficient, and portable hydraulic power where manual operation is required. By using foot pressure, the pump frees the operator’s hands to control tools or position workpieces, making it ideal for workshop and field applications.
Key Features:
- Working Pressure: Up to 10,000 psi
- Two-Stage Operation: Faster low-pressure flow with automatic changeover to high-pressure output
- Durable Steel Construction: Built to withstand industrial use
- Reservoir Capacity: 140.35 in³, pre-filled for immediate use
- Safety Systems: External pressure release valve & factory set safety relief valve
- Wide Foot Pedal: Ensures easy, stable, and controlled pumping action
- Steel Framework: Provides stability and durability in tough environments
| Model number | Valve type | Displacement per stroke (in³) | Usable oil capacity (in³) | Handle effort (lbs) | Weight (lbs) | Dimensions (in) | |||||
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1st stage | 2nd stage | A | B | C | D | E | |||||
| HP227FP | 2-way | 0.79 | 0.14 | 140.35 | 86 | 27.6 | 21.43 | 28.17 | 7.29 | 7.88 | 3.07 |
| HP227FPC | 2-way | 0.79 | 0.14 | 140.35 | 86 | 32.0 | 21.43 | 30.06 | 8.94 | 7.88 | 3.07 |
Product brochure
What is a manually operated foot pump used for?
A manually operated foot pump provides portable hydraulic power by using a foot pedal, leaving the operator’s hands free to position or control tools.
What is the maximum working pressure?
These pumps deliver up to 10,000 psi, making them suitable for demanding industrial tasks.
What makes foot pumps convenient compared to hand pumps?
The wide foot pedal allows hands-free operation, greater stability, and easier control during pumping.
Can these pumps be rented as well as purchased?
Yes. KASI offers industrial foot pumps for rent and sale, suitable for both temporary projects and permanent equipment needs.
Are foot pumps available in Canada and Alberta?
Yes. KASI rents and sells manually operated foot pumps across Canada, with local availability from Edmonton, Alberta.
