Product Overview
KASI supplies portable milling machines for rent and sale across Canada and Alberta, offering a cost-effective solution for on-site industrial milling. Whether you need a simple heat exchanger mill or a large gantry-style machine, our portable mills deliver high precision and productivity directly at the jobsite, eliminating the need to transport workpieces to a machine shop.
Our portable milling machines are designed for industries that require power, flexibility, and accuracy in the field. Built for close tolerance machining, these mills save time, reduce costs, and simplify setup.
Unlike traditional shop-based milling, portable mills bring the machining to your worksite. With versatile mounting options and multiple drive configurations, they adapt easily to your project needs, from small component milling to heavy-duty industrial tasks.
Key Features:
- Versatile Mounting: Weld, clamp, bolt, or magnetically attach to the workpiece.
- Flexible Drive Options: Hydraulic, electric, or air-powered motors.
- Precision Machining: Linear rails, rigid construction, and precision feed screws ensure accuracy.
- Compact & Portable: Easy to transport and set up in tight spaces.
- Powerful Feed Rates: From 20” per minute to 3:1 manual and servo-powered feeds.
Applications include heat exchanger milling, weld preparation, surface machining, and custom gantry-style milling for large-scale projects.
| Size | X-Axis (A) | Y-Axis (B) | Y-Axis (C) Cantilevered | Z-Axis (D) | Length (E) | Width (F) | Height (G) | Weight |
|---|---|---|---|---|---|---|---|---|
| 1000 × 2000 | 76.75″ / 1946 mm | 34″ / 863 mm | 17.25″ / 438 mm | 6.5″ / 165 mm | 106.5″ / 2711 mm | 63.5″ / 1612 mm | 24″ / 609 mm | 1345 lb / 610 kg |
| 1500 × 2000 | 76.75″ / 1946 mm | 53.5″ / 1360 mm | 31.25″ / 793 mm | 6.5″ / 165 mm | 106.5″ / 2711 mm | 63.5″ / 1612 mm | 24″ / 609 mm | 1519 lb / 689 kg |
| 1000 × 3000 | 116″ / 2949 mm | 34″ / 863 mm | 17.25″ / 438 mm | 6.5″ / 165 mm | 146″ / 3707 mm | 63.5″ / 1612 mm | 24″ / 609 mm | 1741 lb / 748 kg |
| 1500 × 3000 | 116″ / 2949 mm | 53.5″ / 1360 mm | 31.25″ / 793 mm | 6.5″ / 165 mm | 146″ / 3707 mm | 63.5″ / 1612 mm | 24″ / 609 mm | 1825 lb / 828 kg |
Product brochure
What are portable milling machines used for?
They are used for on-site precision machining such as heat exchanger milling, weld prep, surface machining, and gantry-style milling, eliminating the need to move workpieces to a machine shop.
How are portable milling machines mounted?
They can be mounted by welding, clamping, bolting, or magnetically attaching to the workpiece, depending on site requirements.
What power options are available?
Our portable mills are available in hydraulic, electric, or air-powered configurations, offering flexibility for different jobsite conditions.
How accurate are portable milling machines?
They use linear rails, rigid frames, and feed screws to deliver close tolerance machining, ensuring precise results in the field.
Can portable milling machines be rented as well as purchased?
Yes. KASI offers portable milling machines for rent and sale, with quick delivery and technical support throughout Canada and Alberta.
